key indicator

.Only in the Americas and Asia Pacific except China

The temperature range of the two models is 0 to 500°C (32 to 932°F).

.Cooling and air purging accessories are optional.

.Stainless steel electronic enclosure that meets IP65 (NEMA-4) standards.

.350 ms response time.

.J type or K type, 0-5 V output.

.12-24VDC/20 mA output.

product manual

The Compact CI series infrared sensors can repeatedly measure the heat emitted from an object and convert the energy into a measurable electrical signal. The target temperature range for Compact CI measurement is 0 to 500°C (32 to 932°F). The Compact CI circuit board is protected by a durable stainless steel case that meets the IP65 (NEMA-4) standard. Without cooling, the sensor head can withstand an ambient temperature of 70°C (160°F); with a cooling jacket, it can withstand an ambient temperature of up to 260°C (500°F).

Spot calculator
