Raytek Compact-GP infrared temperature probe

key indicator



.Only in the Americas and Asia Pacific except China


.Temperature measurement range from -18°C to 538°C (0°F to 1000°F)


.There are two models of standard focal length and close focal length


The functions of the GP display meter and temperature probe can be easily set on the GP display surface panel


.GPS provides laser aiming probe (optional) for measuring small targets










product manual

The GP series is a multi-purpose, two-piece temperature monitoring instrument, which consists of a small, cost-effective display meter and infrared probe. The core part of the system is the 1/8 DIN GP display meter, which has advanced processing functions such as peak/bottom value retention, average value and zero point adjustment. A variety of probes can be connected. The GPR probe is sturdy and durable. There are two models of standard focus and close focus. The accuracy is 1% of the target temperature reading. Thermalert GPM comes with pre-installed cables. Features:

-The temperature range is from -18 to 538°C (0 to 1000°F)

-New generation! GPS laser sight head

-Durable 1/8 DIN digital display meter, 4 digits large window

-Monitor and sensor function settings are located on the front panel

-Has many data processing capabilities that are only available on large systems

-Adjustable emissivity and ambient temperature parameters

-Globally unified 110-220 V AC power supply

-User-set 4-20 mA or thermocouple output (J, K, E, N, R, S, T)

-Adjustable dual set point and dead zone alarm output

-According to different applications, a variety of probes can be connected

-Standard or close focus available

-Cooling and air purging accessories

-Field replaceable probe





Product parameter

Model name / Spectral sensitivity

temperature range

Optical resolution

Applications


GPR Standard Focus

8-14Micron

-18°C~538°C

D:S = 35:1

Printing, coating, laminating, drying/curing, paper, food, textile, carpet, sheet plastic, asphalt, medicine

GPR Close Focus

8-14Micron

-18°C~538°C

D:S = 30:1

S same as above

GPS Standard Focus

8-14Micron

-18°C~538°C

D:S = 50:1

same as above

GPS Close Focus

8-14Micron

-18°C~538°C

D:S = 45:1

same as above



Spot computer
