Main features

.Real-time hotline scanner system for continuous or discrete process measurement

.Up to 1024 measuring points per line

.Fast scan rate up to 150 lines per second

.Optical resolution up to 200:1

.Built-in line laser for quick alignment

.Onboard Ethernet TCP/IP communication

.Various models and spectral response options

Product overview

Raytek MP150 infrared hotline scanner is designed for demanding industrial environments and provides accurate temperature images of moving objects. This multi-point measurement is achieved through a rotating optical system, which can collect up to 1024 points of infrared radiation within a 90º field of view. The motorized mirror scans at a speed of 150 lines per second.

The internal high-speed microprocessor calculates the temperature of each measurement point of each row of data. The MP150 hotline scanner includes air-cooled or water-cooled equipment, three configurable analog outputs and two-way digital communication. The hot-line scanner also has onboard Ethernet TCP/IP communication function and built-in line laser for quick alignment.

Provide optional analog or digital output module. MP150 Process Imager Systems can select temperature and spectral range. For details, please consult the product manual and data sheet.

Raytek DataTemp®DP

The MP150 hotline scanner can be used independently, can be connected to a single PC, or it can be integrated into a comprehensive process control system using DataTemp®DP (an industrial Windows® software package), which provides remote configuration of the imager And real-time monitoring. the process of. Using the OPC Server function of the DataTemp DP software, the line scanner becomes an integral part of any OPC-compliant distributed control interface (DCI) or human-machine interface (HMI) system. In all cases, MP150 provides real-time monitoring and control functions.

Spot calculation
