Features
Heating controller QUICK 378FA
1. High frequency eddy current heating technology, rapid heating;
2. Sensor front technology, strong temperature compensation;
3. Intelligent temperature control system, accurate and stable temperature;
4. Abnormal temperature alarm and output function;
5. RS485 communication function, which can communicate with PC/PLC, monitor and set the temperature in real time to ensure the welding process.
Device parameters
Product Image |
|
|
|
model | QUICK ET9383EZB | QUICK ET9483EZB | QUICK ET9583EYAZB |
power supply | 100~240VAC | 100~240VAC | 100~240VAC |
power | 500W | 500W | 500W |
Motor control axis | 3axis | 3axis | 3axis |
Axis dynamic range | X/Yaxis | 300 mm | 400 mm | 500 /400mm |
Zaxis | 100 mm | 100 mm | 100 mm |
Processable product range | 240*300 mm | 340*400 mm | 400*400 mm |
Shaft speed range | X/Yaxis | 0.1～800 （mm/sec） | 0.1～800 （mm/sec） | 0.1～800 （mm/sec） |
Zaxis | 0.1～300 （mm/sec） | 0.1～300 （mm/sec） | 0.1～300 （mm/sec） |
Repeat position accuracy | X/Y/Zaxis | ±0.01mm | ±0.01mm | ±0.01mm |
Load weight | Yaxis | 8 Kg | 8 Kg | 8 Kg |
Zaxis | 5 Kg | 5 Kg | 5 Kg |
Teaching file capacity | Up to 999 files, up to 60000 points |
Processing file capacity | Up to 255 files | Up to 255 files | Up to 255 files |
Use environment | Temperature | 0～40℃ | 0～40℃ | 0～40℃ |
Humidity | 20％～90％(No condensation) | 20％～90％(No condensation) | 20％～90％(No condensation) |
Dimensions W×D×H | 485*610*650mm | 585*710*650mm | 685*710*650mm |
weight | 40Kg | 45Kg | 55Kg |
